Lift Travel Cables | 4 SM Fiber + 10 Core
The Netcon Hybrid Flat Elevator Cable, featuring 4F Single-Mode Fiber Optic for high-speed data and 10 Core 1.5 sqmm (16 AWG) multistrand copper conductors for reliable power delivery, is a compact, flexible, and durable solution designed to support modern smart elevator systems, high-rise vertical transport, and intelligent control applications by combining seamless power transmission and communication in one robust flat cable.
| Name | Certificate |
|---|---|
| ROHS Certificate | View Certificate |
| Test Report | View Certificate |
| CE Certificate | View Certificate |
| IEC Certificate | View Certificate |
| ENVIRONMENT | |
|---|---|
| Jacket Material | PVC / LSZH |
| Water Blocking | Gel-filled or dry tube options available for moisture resistance |
| Temperature Range: | Operating: -15°C to +70°C Storage: -40°C to +85°C Installation: -20°C to +60°C |
| FIBER OPTIC COMPONENT | |
| Coating Diameter | 1310 nm and 1550 nm |
| Wavelengths Supported | ≤ 0.35 dB/km at 1310 nm |
| Cable Cutoff Wavelength | ≤ 1260 nm, 9.2 μm ± 0.4 μm at 1310 nm |
| Travelig height | 250 Mtrs |
| Cable Type | 4 -core Single Mode (ITU-T G.657A1 or G.652D) |
| Minimum Bend Radius | 10x cable diameter during installation, 5x cable diameter post-installation |
| Data Transmission Distance & Speed | 1 Km @ 10 Gbps |
| Running Speed | ≤ 6 M/s |
| Optical Characteristics | 9 μm (core) |
| Bandwidth | Typically >10 GHz·km at 1550 nm |
| Max Suspension Length | 80-100 Meters |
| Attenuation | ≤ 0.22 dB/km at 1550 nm |
| Core Diameter | 125 μm |
| Cladding Diameter | 250 μm |
| POWER CABLE COMPONENT | |
| Insulation Resistance | ≥ 20 MΩ·km at 20°C |
| Cable Type | 10 Core 16 Awg, Multi Strand Copper |
| Voltage Rating | 300/500V (IEC 60227) 450/750V (IEC 60502-1 ) |
| Current Carrying Capacity | 5 -10 Amps - based On Application |
| Conductor Resistance | Per IEC 60228, approximately 12.1 Ω/km at 20°C for 1.5 sqmm copper |
| MECHANICAL CHARACTERISTICS | |
| Conductor Classifiaction | IEC 60228 Class 5 |
| Standard | EN50214 |
| Elements | 4C Single mode Fibre cable with 10 Core x 16 Awg Copper core |
| Mx. Distance for Power Cable | 12V DC, 5A : 35Mtrs / 24V DC, 5A :58 Mtrs / 230V AC, 10A : 480 Mtrs |
| Insulation Material | PVC / XLPE |
| Sheath Material | PVC / LSZH, Grey |
| Bend Radius | 10x the cable thickness during installation, 5x the cable thickness in static conditions |
| GENERAL | |
| Coax | Grey |
| Outer sheath material | PVC |
| Outer sheath colour | Grey |
| Core | Black, white numbered, G = with green-yellow core(s) |
| Pair/quad | Various colours or black with white numbers |
| Operating temperature | -15 °C - +70 °C |
| ELECTRICAL PROPERTIES | |
| Rated voltage Uo/U | According to table |
| MECHANICAL PROPERTIES | |
| Recommended loop diameter | According to table, tolerance -50/+100 mm |
| Acceleration | 1.2 m/s² |
| Maximum free suspension | 100 m |
| Maximum running speed | 6.0 m/s |
| Maximum travelling height | 250 m |
